BIO-SEA ‘L’ – SKID solution for yachts
BIO-SEA ‘L’ SKID for yacht – The smallest ever UV ballast water treatment system on the market with all-in-one equipment shrank as a compact plug-and-play solution
Benefits of BIO-SEA ‘L’
- The most compact UV BWTS on the market
- No need for additional power cabinet
- High grade marine quality materials and components made in France
- Reduced number of lamps with the right UV dose & power regulation
- Safe: no chemicals, no by-products, no active substances
- System performance unaffected by variations in water temperature or salinity
- Automatic operation, user-friendly interface
- Easy to install, operate and maintain
- Cost effective, low OPEX solution
- Fully customizable
Options
- Painting (high-gloss yacht finish)
- CuNiFe piping
- Drip tray
- Remote control panels
Specifications
| Treatment Capacity | from 13 to 120m3/h |
| Power Supply | 400-440 V; 50-60 Hz; 3-phases |
| Power Consumption per UV reactor | 6 kW |
| UV lamp lifetime | 5000 hours |
| Environmental Operating Conditions | IP54; T° = 0°C; H% < 95 |
| Global Head Loss | < 0.55 bars |
| Operating Pressure | 1.5-10 bars |
BIO-SEA ‘L’ for Yacht – Product sheet
